H4D
Parts, components & control panel buttons
The buttons are used for browsing images and navigating the menu system to make settings. Two of the buttons, located at the
bottom-right and -left of the screen, are given an on-screen label that changes according to the current context. For example, the Ap-
proval button sets the approval rating when browsing images, but becomes an OK button to con rm settings.
Zoom- in/-out button A
Zoom-in/outrockerbuttonforthepreviewimage.Youcanzoom
intoviewclose-upsofpreviewsforfocuschecking.Youcanzoom
outtoviewseveral atonceandnallytoviewandselectbatches
andmedia.Alsoactsasaselectionbuttonforvaluesettingon
themenu.
MENU/(EXIT)button B
Opensandclosesthemenusystem.Alsousedforvari-
ousothertasks(EXITbutton,forexample)asyouissue
commandswithinthemenusystemindicatedbyade-
scriptionbesidethebuttononthepreviewscreen.
Navigationbutton C
Afour-wayrockerbuttonenablingyoutostepthroughpre-
viewimagesandnavigatethemenusystem.Touseit,press
thesideofthebuttonthatcorrespondstowhatyouwishto
do(e.g.,moveup,left,rightordown).
Display D
Thedisplayisa3inch,TFT,24bit,230,000pixeltype.Contrastandbril-
liancecanbeadjusted.
View-mode button E
Stepsthroughthevariousviewmodesforthepreviewim-
age:standard,histogram overlay, imagedetails,screeno
andfull-screen.
K L M N OP
A
B
C
D
E
F
G
H
I
J
