4.2 Design of the camera measurement head
Camera measurement head with main components:
Never remove camera shaft from the 3-arm star!
The camera shaft is permanently mounted onto the 3-arm star. It was adjusted and
calibrated after mounting.
If (e.g. after a fall) you suspect that the camera shaft is not vertical to the 3-arm star
anymore, please contact your supplier!
