18 Fault-finding and correction
Operators may only themselves attempt to rectify such faults that are clearly due to op-
erating or maintenance errors!
18.1 Description and causes of faults
Description Possible causes Fault correction
There is no connection estab-
lished to the cameras after
program start
• Not enough battery power
left.
• Incorrect interface connec-
tion specified in the pro-
gram.
• No or incorrect radio chan-
nel for camera connection
No USB driver for the re-
ceiver installed on the oper-
ating system
• Recharge the batteries in the
camera measurement heads
using the charging unit sup-
plied
• After program start, select the
"Settings" button; interface
should be set to AUTO
(see Pnt. 7.2.3)
• Try to establish a new con-
nection with another radio
channel
Install the USB driver which is on
the USB-Stick (Pnt.6.3, Page 18)
The camera does not detect
any signal from the reflectors
The reflectors are severely
damaged or dirty
Clean reflectors or replace with
new ones, if necessary
Camera measurement head is
not seated securely on the rim
• Dirty rim surface
• Dirty magnetic feet
• No full-surface contact by
the magnets with the rim
• Clean rim surface
• Clean magnet surface
• Re-align magnetic feet
Measurement results are un-
realistic
• Front reflector distance from
left to right differs from the
rear distance from left to
right
• Measurement head align-
ment incorrect
• Check distances! Same re-
flector distances at front and
back.
• Check by carrying out a run-
out test of the wheel align-
ment clamp and re-measuring
the toe, if necessary contact
the Service department
