2.2 Configuring the hardware
2.2.1 Voltage supply / Transducer
• Connect the power supply cable and the transducer to the module
(Chapters 5.3 and 5.4).
CAUTION
Be sure to comply with the safety instructions!
• Activate the power supply.
• The device will run a self-test (approx. 10 secs) and will then, if working
properly, be in measuring mode. During the self-test, the control
outputs stay at 0V.
NOTE
If ! appears in the display or the status LED shows red, please consult
Chapter 7 ”Error messages”.
• Connecting the bus system
To find out how to connect several devices to a CAN bus, refer to Chapter 5.5.
How to set up the CAN address and the baud rate is described in Chapter
2.1.3.
