21
PME-MP85
A0897−3.4 en HBM
2.4.2 Using the USB interface
To configure the USB interface, perform the following steps:
• Start the PME Assistant program and in the startup window, enter the
interface details.
1. In the <Interface type> dropdown list box, select the mode PCAN USB
2. In the <CAN-Baudrate> dropdown list box, select the baud rate to be set
for the connected PME modules.
If you do not know the setting, you can use the keyboard of a PME module
to query it (see Page 2.1.1 ).
NOTE
The baud rate must be the same for all the PME modules connected to
the CAN bus. The factory setting is 1000 kB.
5. Click the <Scan> button.
In a few seconds, the addresses of the connected PME modules will be
listed in the <CAN-ID> dropdown list box in the Devices area.
6. Select a module and click on <SET>. This opens the Setup window (see
Online Help).
You can now use the PME Assistant software to set up the MP85.
This is described in the Online Help.
