HBM MP85 - Page 44

44
PME-MP85
A0897−3.4 enHBM
Nomin
al
(rated)
value
fc (Hz)
−1dB
(Hz)
−3dB
(Hz)
Phase
delay
(ms)
Rise
time
(ms)
Over-
shoot
(%)
off 790 1200 0.450 0.290 3
1000 980 1400 0.550 0.260 4
500 440 690 0.860 0.510 1.5
Measurement frequency range,
200 190 320 1.6 1.11 1.5
Measurement frequency range
,
adjustable
100 100 160 2.9 2.13 1.3
adjustable
Low pass 4th order with Bessel
50 51 83 4.6 4.24 1
Low pass 4th order with Bessel
characteristic
20 25 41 8.2 8.36 1
characteristic
10 13 21 15.5 16.8 0
5 6.1 10.3 30.2 33.4 0
2 3.1 5.2 60 67 0
1 1.6 2.6 119 137 0
0.5 0.79 1.30 240 272 0
0.2 0.19 0.32 950 1070 0
0.1 0.09 0.16 2500 2170 0
0.05 0.049 0.081 3750 4280 0
Shunt calibration mV/V 1"3%
Effect of operating voltage
on zero point
on sensitivity
% f.s.
% f.s.
t0.01
t0.01
Effect of 10 K change in ambient
temperature
Measuring range (mV/V)
4 100 1000
on zero point full bridge
on zero point half bridge
on sensitivity
µV/V
µV/V
%
1
10
0.05
20
40
0.05
200
200
0.05
Long-term drift over 48 h(meas. range
4 mV/V; 0.5 h after powering up)
µV/V 2
DC-voltage transducer
Attachable process quantity transducer DC-voltage transducer, voltage sources
Nominal (rated) measuring range V "10
Input signal range V "10.5
Scale range, max. Digits 999999, at 10 % of input measuring range
Scale range, min. Digits 100, at 100 % of input measuring range
Internal resistance of the signal source kΩ v1
Maximum permitted common-mode
voltage
V 2
Measurement frequency range,
adjustable (-1 dB)
Hz 0.05 − 1000
Filter characteristics Bessel, 4th order
Linearity deviation % t0.03
Sampling rate max. 1/s 2400
