Configuring the Spider8 with the Setup program Ý Channel-specific menus
Spider8
Mark Chan. Name Trans. Meas. Rng. Filter Tare Shunt Tare Val. Meas. Value
Measuring range:
The available measuring ranges are displayed in accordance with
the transducer selected.
Transducer
Full bridge
Half bridge
DC voltage
Meas. Rng.
3mV/V
12mV/V
125mV/V
500mV/V
10V
Chan.
Channel 0 and
1 only
0...3; 4...7
(SR55, SR30)
1MHz
100kHz
10kHz
1kHz
10ms
100ms
1s
10s
100s
Cnt
Cnt/100
Signal edges
Signal edges + direction
2 phases, 1x
2 phases, 4x
Quarter bridge
1)
1)
