HBM Spider8 - Page 56

D-6
Connecting Ý Connecting transducers
Spider8
The following transducers can be connected to the Spider8:
Transducer 4.8kHz carrier-fre-
quency module
1)
600Hz carrier-fre-
quency module
2)
DC module
Channel Channel Channel
S/G full bridge
S/G half bridge
S/G quarter bridge
0...7
0...7
-
0...7
0...7
0...7
-
-
Inductive full bridge
Inductive half bridge
0...7
0...7
-
-
-
-
DC 10V
DC 1V
100mV DC
0..7
-
-
0...7
-
-
0...7
0...7
0...7
DC current - - 0...7
Frequency (counter) 0, 1 - -
Resistance - - 0...7
Potentiometer 0...7 0...7 -
Thermocouple - - 0...7
1)
not for Spider8-30 and Spider8-01/55
2)
not for Spider8-01/30
