72 IT 1002 Order No BA 93-66-1206 Issue 03.11.08
Spare part list power element complete IT 1002 (88-17-929)
Pos. Quantity Order No. Description
1 1 88-14-158 Bottom plate
3 1 88-13-170 Rear wall
5 1 88-14-159 Screen angle plate
7 1 88-14-160 Intake channel
31 1 80-70-429 Power unit
39 4 80-10-203 Casing feet
41 10 80-11-111 Cage nut M4
43 3 80-11-121 Flat connection
51 1 80-11-358 Conductor mark PE-ground cable
53 3 80-11-359 Conductor mark ground cable
60 1 80-11-669 Wire protecting sleeve
70 2 80-10-050 Flat connection
71 4 80-90-173 Screw M4 x 10
72 1 80-90-404 Screw M4 x 25
73 4 80-90-191 Screw M4 x 8
75 2 80-90-261 Screw M4 x 10
77 4 80-90-319 Screw M4 x 8 black
81 3 80-90-184 Tooth lock washer A4
85 6 80-90-164 Washer 4 mm
89 8 80-90-121 Spring washer 4 mm
93 4 80-90-153 Nut M4
101 5 80-90-386 Screw M6 x 14
103 2 80-90-320 Screw M6 x 20
105 1 80-90-387 Screw M6 x 25
109 4 80-90-197 Tooth lock washer A6
113 8 80-90-198 Washer 6 mm
117 8 80-90-147 Spring washer 6 mm
121 7 80-90-146 Nut M6
8 Appendix
8.2 Spare Parts
