HVAD
®
Pump Overview
Introduction
108 HVAD® Instructions for Use
2
4
6
5
1
3
7
6.1 Preparing for Implantation (continued)
Equipment for Implant (continued)
Figure 97: Components used at Implant
1
HVAD
®
Pump
2
Out ow graft
3
Sewing ring (made of titanium and polyester)
4
Driveline cap
5
Strain relief
6
In ow cap
7
Driveline extension cable
A set of surgical tools (provided ETO sterilized) is also required for implantation of the device (Figure 98).
Figure 98: Surgical Tools
1
Tunneler – to tunnel the pump’s percutaneous driveline through the skin to the exit site
2
Sewing ring wrench – to tighten the screw on the sewing ring
3
Driveline cover – to cover the driveline connection to the controller
4
Apical coring tool – to core the LV apex
5
Hex driver –
®
Pump
All tools and accessories used during implantation are for single-use only.
4
5
1
2
3
CAUTION:
air or with oxygen or nitrous oxide. (: Flammable anesthetics are typically ether based).
