PumpOverviewIntroduction
51HeartWare™ HVAD™ System Overview
System Component Overview
See Appendix A for a complete list of system components.
The primary components of the HeartWare
™
HVAD
™
System (excluding the Monitor) are intended for single
patient use.
STERILE: All HeartWare implantable components, surgical
tools and accessories used at implant are provided
sterile.
2.1 HVAD
®
Pump and Surgical Tools
The HeartWare
™
HVAD
™
System consists of a blood pump
graft, and a percutaneous driveline. A strain relief is
wrapped with woven polyester fabric to encourage
tissue in-growth at the skin exit site. The small, wearless
pump has a displaced volume of 50cc and weighs 160
grams. The pump has one moving part, an impeller, which
two motors in the pump housing with one motor providing
redundancy.
®
Pump
to the aorta. A sewing ring attaches to the myocardium
and allows for pump orientation adjustments
allow for pericardial placement, which eliminates the
need for abdominal surgery and device pockets
(Figure 24).
Figure 24: HVAD
®
Pump and Left Ventricular (LV) Cannulation
2.1 HVAD
®
Pump and
Surgical Tools .............51
2.2 HVAD
®
Controller ....................52
2.3 HeartWare
®
Monitor .......................53
2.4 HVAD
®
Controller
Power Sources ...........53
2.5 HeartWare
®
Battery Charger .........54
2.6 Carrying Cases and
Shower Bag
................54
2.0 HeartWare
™
HVAD
™
System Overview
For additional information about the HVAD
®
Pump,
see Section 3.0.
