05 STARTUP
SCHEDULES MENU
The Schedules menu is used to configure schedules that are used to set an absolute temperature. Up to four
periods can be configured per day. Each period can have its own start time and temperature setting, and will
maintain that temperature setting until the next scheduled period start time.
