heat-timer ETS-LT - Ets-Lt Sizing

8
|
HEAT-TIMER CORP.
059327–00 REV. C
PRESSURE
DROP PSI
ETS MODELS
ETS–75 ETS–100 ETS–125
Cv 7 12 18
3 12 20 32
4 15 23 37
5 16 26 41
6 18 28 45
7 20 31 50
8 21 33 53
9 22 35 56
10 23 36 58
11 24 38 62
12 25 40 64
BUILDING
RECIRC
5 GPM 5 GPM 10 GPM
GALLONS PER MINUTE
03 SPECIFICATIONS
ETS-LT SIZING
ETS
MODEL
PART
NUMBER
ETV
VALVE
SIZE
PIPE SIZE
A B C D E F G H J K WEIGHT
MIXED COLD HOT RECIRC
HEAT SOURCE
COLD SUPPLY
ETS-75 915800–75 ¾
”
¾
”
¾
”
¾
”
¾
”
¾
”
36.00 26.00 10.50 16.00 18.70 1.50 3.75 2.50 3.00 3.81 52 lb
ETS-100 915800–100 1” 1” 1” 1” ¾
”
1” 36.00 26.00 10.50 16.00 18.70 1.50 3.75 3.00 2.25 3.94 58 lb
ETS-125 915800–125 1 ¼” 1 ¼” 1 ¼” 1 ¼” ¾
”
1 ¼” 36.00 26.00 10.50 16.00 18.70 1.38 3.75 3.38 2.00 4.06 68 lb
