059327–00 REV. C
HEAT-TIMER CORP.
|
9
03 SPECIFICATIONS
ETV PLATINUM PLUS CONTROL MODULE
Voltage Input 120Vac 60Hz
Maximum Input Rating 48VA max
Dimensions (W x H x D) 11” x 9” x 3 ¾” (279.4mm x 228.6mm x 95.25mm)
Weight 2.5lbs (1.13kg)
Modes of Operation ETV, HTLV, ETV + HTLV
ETV Setpoint 40°F to 200°F (4°C to 93°C)
Alarm Setpoint 40°F to 200°F (4°C to 93°C)
Modulation Output Signal 0–10V (default), 2–10V, 0–5V, 1–5V, 4–20mA
Output Relays 1 HTLV Lockout
1 Modem Reset
1 Valve Output
Output Relay Rating HTLV Lockout: 3A at 120Vac 60Hz
Modem Reset: 5A resistive at 120Vac 60Hz
Valve Output: 1A inductive at 120Vac 60Hz
Inputs System Temperature, Aux Temp 1 (Temp or Switch), Aux Temp 2 (Temp or Switch)
Flow Prove, Remote Setpoint (4–20mA)
User Interface Digital Display
Display Units: Temperature (°F and °C)
Status Indicators (3 LEDs)
Variable-Function Buttons (4)
ETS-LT ACTUATOR
Voltage Input 24Vac 60Hz
Power Consumption 18VA max
Input Signal 0–10V
Weight 2.6 lbs (1.2 kg)
ETS-LT VALVE BODY
Body and Trim 304 Stainless Steel
Maximum Operating Temperature 300°F (149°C)
Maximum Working Pressure 225 psi
Stem Material 640 Stainless Steel
