02 CONTROLS, INDICATORS, AND CONNECTIONS
ITEM DESCRIPTION
1 Electronic Temperature Controller
(ETV Platinum Plus)
2 ETV Valve Body with Actuator
3 Temperature Sensor
4 Recirculation Water Line
ITEM DESCRIPTION
5 Boiler Feed Line
6 Cold Water Line
7 Tempered Water Line
8 Hot Water Line
FIGURE 1
ETS-LT CONTROLS, INDICATORS, AND CONNECTIONS
1
3
4
7 6
5
8
2
