www.heras.com
English
10
Illustration 3: iGate sliding gate terms
Illustration 4: SHB sliding gate terms
bottom rail
IGD
road wheels
running surface
head stile
slam support
slam column
anti-crushing safety protection device
top rail + LED
lighting
perforated
plating
guide column
flash light
HMD
slam post
anti-crushing safety protection device
bottom rail
guidepost
bars
