10.4 MENU 4 - SETTINGS
Several settings can be programmed here.
10.4.1 Menu 4.1: Timer settings
10.4.1.1 Menu 4.1.1: Set lighting (coming home - leaving home)
The HMD230 can drive a lamp, e.g. to automatically light the zone around the gate when the gate is
moving. The lamp must be installed by an engineer (password required).
See the chapter on “Parameter settings” in the HMD230 motor drive installation manual.
The connected lighting (max. 230 VAC /3A) is activated by the drive unit as soon as a movement
command is detected. After the motor is switched off, the lamp will continue to be lit for the time as
set (1 to 1800 seconds). This parameter "Lighting (s)" can be set to the user's preference.
