16 TECHNICAL DATA
16.1 SLIDING GATE DESCRIPTION
Gate leaf
Delta
uGate
Orion
iGATE
SHB
Length [m]
5.15 … 12.5
9.74 … 16.3
7.00 … 16.6
4.7 … 12.3
3.55…133.3
Height [m]
1.00 … 2.5
1.5 … 2.5
2.00 … 2.5
1.5 … 2.5
1.5 … 2.5
Max. weight [kg]
340
450
575
260
610
Construction
cantilever
cantilever
cantilever
cantilever
On rail
Type of drive
HMD230S
HMD230A
Motor
MOTHR80P (standard motor)
MOTHR80PAO (with automatic disengagement)
Supply voltage [VAC]
1 phase 230V
AC
/N/PE ±10% 50/60Hz
External power supply 230V
230VAC ±10% 50/60Hz, fused with a 6.3A slow-acting fuse on
the PCB
Internal power supply 24V
24V
DC
stabilized (±5%) max. 500mA
(fused with a semiconductor fuse that resets automatically) for
optional accessories
Motor power [kW]
0.37
Control inputs
24V
DC
/ typ. 4mA
< 12 V: inactive -> logical 0
> 18 V: active> logical 1
(galvanically isolated internally)
Local fuse
max. 10A
Max. torque [Nm]
80
Duty cycle [%]
100
Anti-crushing safety
GE 365, GE 3555
GE 499, GE F85SK
Crawl speed [m/s]
0.13
0.25
Max. speed [m/s]
0.25
0.50
IP category of control cabinet
54
Temperature range
-16 °C to +55 °C
Relative humidity range
max. 99% non-condensing
Weight [kg]
22
