Sl. No.
Description
Function
13
18
Fuel gauge
Service reminder
indicator
Displays when the next service is due (page 22).
12
11 Next service distance
Indicates how many kilometers are left before the
next service is due. It appears for few seconds when the
ignition switch is turned “ON” ( ) (page 22).
Indicates approximate fuel available in the form of
digital segments. The digital segments will swing to
maximum scale on the meter console once the ignition
switch is turned “ON” ( ) (page 22).
10
Set button
To adjust clock, date & tripmeter.
When long pressed resets tripmeter to zero.
16
15
14
Odometer
Shows accumulated distance travelled (page 20).
Speedometer
Indicates hours & minutes .(page 19)
Digital clock
Indicates .riding speed
Gear indicator Displays the selected gear while riding (page 24).
17
Mode button
Switches display between odometer, tripmeter-1 & 2,
clock, Eco mode & Bluetooth connectivity.
9
lamp (MIL)
Programmed-FI
malfunction indicator
When the ignition switch is turned “ON” the programmed
FI malfunction indicator lamp (MIL) glows continuously
and then should go “OFF” once the engine is started. It
indicates that programmed FI system is OK. If it glows
continuously there is an abnormality in the programmed
FI system, it is recommended to reduce the speed and
drive to the Authorised Hero MotoCorp workshop for
check-up.
