HERO XPULSE 200 PROGRAMMED FI - THROTTLE OPERATION; Throttle Cable Inspection

56
Cable inspection
Check for smooth rotation of the throttle grip
from the fully open to the fully closed position.
Check at full left and full right steering
positions. Inspect the condition of the throttle
cable from the throttle grip down to the
throttle body. If the cable is kinked, chafed or
improperly routed, it should be replaced or
•
Check for clutch cable routing.
THROTTLE OPERATION
Other checks
•
Check the clutch cable for kinks or signs of
wear that could cause sticking or failure.
•
Check for clutch cable model. Use genuine
clutch cables.
If proper adjustment cannot be obtained or the
clutch does not work correctly, visit your
Authorised workshop.Hero MotoCorp
NOTE
Free play adjustment
To adjust the free play, slide the boot (2), then
loosen the lock nut (4). Turn the adjuster (3)
to adjust free play. After adjustment, tighten
the lock nut and slide the boot on the adjuster
and locknut securely.
(1) Free play: 2-6 mm
(2) Boot (3) Adjuster (4) Lock nut
(A) Decrease free play (B) Increase free play
B
A
2
3
4
B
A
(3) Lock nut (4) Clutch cable adjusting nut
(A) Decrease free play (B) Increase free play
3
4
rerouted. Standard throttle grip free play (1)
is approximately 2-6 mm of grip rotation.
1
