66
(1) Main stand (optional) (2) Side stand
The tyres that are fitted on your vehicle are
designed to match the performance
capabilities of handling, braking, durability and
comfort.
TYRES
The imported tyre(s) if fitted without ISI mark;
are in compliance of BIS standard and Central
Motor Vehicle Rules 1989, as declared by the
Tyre manufacturer.
NOTE
To safely operate your vehicle, the tyres must
be of recommended type and size, in good
condition with adequate tread, and correctly
inflated. The recommended tyres size is :
Air pressure
Properly inflated tyres provide the best
combination of handling, tread life, and riding
comfort. Generally, under inflated tyres wear
unevenly, adversely affect handling, and are
more likely to fail from being overheated.
surface hazards and wear unevenly.
The recommended “cold” tyre pressure are:
Under inflated tyres can also cause wheel
damage in rocky terrain.
Over inflated tyres make your vehicle ride
more harshly, are more prone to damage from
Make sure the valve stem caps are secure.
If necessary, install a new cap.
Rear
90/90-21 M/C 54S
120/80-18 M/C 62S
Front
•
Install the indicator plate (6) and tighten the
rear axle nut (7) to the specified torque.
TORQUE : 6.9 kgf-m
• Adjust the drive chain slack (page 57).
MAIN STAND (OPTIONAL)/
SIDE STAND LUBRICATION
• Park the vehicle on the level surface.
• Check the main/side stand return spring for
damage or loss of tension.
• Check the main stand (1)/side stand (2)
for freedom of movement.
• Lubricate the side stand.
• Make sure the main/side stand is not bent.
Front
Rear
2
1.75 kgf/cm (25 psi)
2
2.30 kgf/cm (33 psi)
2
1.75 kgf/cm (25 psi)
2
2.50 kgf/cm (36 psi)
Rider only Rider and Pillion
12
