30
(1) Ignition key
The rubbers (1) of the rider footrest (2) (both
side) are detachable and can be detached for
“OFF-ROAD” riding only {refer off-road
safety guide line (page 11)}.
While installing the rider footrest rubbers, the
projections (3) of the rider footrest rubbers
must be attached to the rider footrest properly.
(f) Rider footrest
(1) Rubbers (2) Rider footrest
(3) Projections
1
2
3
1
Left handlebar controls
HANDLEBAR SWITCHES CONTROL
The headlamp operates only when the engine
is running.
“ ” downwards for low beam “ ”.
Press the pass switch to “PASS” position to
operate the pass lamp.
1. Headlamp dimmer switch/Pass
switch
Press the switch (1) upwards for high beam
Shift the turn signal switch (2) sideways for
right/left indications and leave it to come
back to its normal position on its own.
2. Turn signal lamp switch ( )
IMPORTANT: To switch “OFF” the turn
signal after completing the turn, gently push
the switch inside.
(1) Headlamp dimmer switch/Pass switch
(2) Turn signal switch
(3) Horn switch
1
3
2
