Ÿ Start the engine & let it idle for 3-5
minutes.
Ÿ Slightly loosen the engine oil check bolt (4)
and check the engine oil entry into the
cylinder head cover.
Ÿ Do top up if oil level reaches towards the
lower level mark or every 3000 km
whichever is earlier.
Ÿ Park the vehicle on its main stand.
(4) Engine oil check bolt
49
GRADE: SAE 10W 30 SL Grade
BRAND: Hero 4T plus
Ÿ Tide Water Oil Co. (India) Ltd.
Engine oil level inspection/
Ÿ Bharat Petroleum Corporation Limited.
Ÿ Savita Oil Technologies Limited.
Manufactured by:
Check engine oil level each day before
operating the vehicle. The oil level dipstick (1)
is on the right crankcase cover for measuring
oil level. Oil level must be maintained between
the upper (2) and lower (3) level marks on
the oil level dipstick.
Use hero genuine engine oil or recommended
grade oil.
Top up process
OIL CAPACITY : 1360 ml
(JASO MA2).
ENGINE OIL
Ÿ Quantity of oil to be filled is 1170 ml
(approx.) during oil change (when right
crankcase cover is not removed).
Ÿ Remove the oil level dipstick and check the
oil level.
Ÿ Remove the oil level dipstick, wipe it clean
and insert without screwing it in.
Ÿ If required, add the specified oil up to the
upper level mark. Do not overfill.
Ÿ After checking the oil circulation, tighten the
engine oil check bolt.
Ÿ Stop the engine and wait for 2-3 minutes.
4
(1) Oil level dipstick (2) Upper level mark
(3) Lower level mark
3
2
1
