HERO XPULSE 200 PROGRAMMED FI - Fuel Gauge and Service Reminder Operation

22
If only one segment (3) is displayed and
blinks, this indicates the fuel quantity is low
and the fuel tank should be refilled as soon as
possible.
(c) Fuel gauge
The fuel gauge (1) indicates approximate fuel
available in the form of digital segments.
The digital segments (2) will swing to
maximum scale on the meter console once the
ignition switch is turned “ON” ( ). If all the
segments are displayed it means fuel quantity
in the fuel tank is 13.0 litres.
(1) Fuel gauge (2) Segments(1) Fuel gauge (2) Segments
(3) One segment
Please ensure the vehicle is not used
continuously when the fuel level indicator
reaches the one segment blinking. It will not only
result in the vehicle running out of fuel, it may
also cause serious damage to the fuel pump.
Please ensure fuel is filled up as soon as the fuel
level indicator reaches one segment blinking.
CAUTION
!!
NOTE
To check the fuel level indication, the vehicle
should be on levelled surface and in stationary
condition.
1
2
3
(d) Service reminder indicator
The service reminder indicator (1) is to
indicate the user to bring the vehicle to an
Authorised Hero MotoCorp workshop for
service. The indicator shall start blinking when
the vehicle covers kilometers as specified in
the maintenance schedule. The indicator will
keep on blinking throughout the kilometer
interval for a particular service and will stay
‘‘ON’’ thereafter.
Meter console also displays the next service
distance (2). It indicates how many kilometers
are left before the next service is due. It
appears for few seconds when the ignition
switch is turned “ON” ( ).
(1) Service reminder indicator
(2) Next service distance
x 000I
F FF
E
EE
km/h
RPM
Gear
ODO
ODOODO
km
0
00
I
II
2
22
3
33
4
44
5
55
6
66
7
77
8
88
9
99
IO
IOIO
II
IIII
241.6 km
to go
Serv
241.6 km
to go
Serv
