HERO XPULSE 200 PROGRAMMED FI - Side Stand Engine Kill Feature

33
Ensure that adequate care should be taken
while cleaning the side stand switch.
CAUTION
!!
•
If the side stand indicator (1) does not
operate as described in above steps, please
visit your Authorised Hero MotoCorp
workshop.
•
Check the side stand for proper function
and the spring (3) for damage or loss of
tension and the side stand assembly for free
movement.
•
While the side stand is up, the side stand
indicator (1) should not glow.
•
Check whether the side stand indicator (1)
glows when the side stand is down.
•
It prevents starting the engine when
transmission is in gear (irrespective of
clutch lever operation) and side stand is
down.
Your vehicle is equipped with “Side
stand engine kill” feature for safety
purpose.
This feature has following functions:
•
It stops the running engine when
transmission is in gear (irrespective of
clutch lever operation) and side stand is
moved down.
INSPECTION FLOW DIAGRAM
2. Then shift the transmission to gear (with
engine running and irrespective of clutch
lever operation).
Does engine stop?
Visit Authorised
Hero MotoCorp
Workshop
NO
1. Press the electric starter switch (with
transmission in neutral and side stand is
down).
3. Now press the electric starter switch (After
engine has stopped).
NO
SYSTEM IS OK
Does engine start?
YES
Visit Authorised
Hero MotoCorp
Workshop
NO
YES
Does engine start?
Visit Authorised
Hero MotoCorp
Workshop
YES
WARNING
!!
“Side stand engine kill” system is not affected
by clutch lever operation.
To inspect the functionality of this feature,
park the vehicle on its main stand and check
all the conditions described in the inspection
flow diagram:
