HERO XTREME 160R PROGRAMMED FI - RIGHT SIDE VIEW; Right Side View Components

6
*Accessories and features shown may not be part of standard fitment.
(1) Rear brake fluid reservoir
(2) Rear master cylinder
(3) Brake pedal
(4) Kick starter pedal
(5) Oil level dipstick
(7) Front disc
(6) Front caliper assembly
(8) Fuel tank cover
(10) Fuse box (inside)
(11) Document & Tool kit compartment
(12) Rear caliper assembly
(13) Exhaust muffler
(9) Seat
(14) Rear disc
RIGHT SIDE VIEW
3
11
8
2
7
9
13
14
12
10
1 4 5
6
