HERO XTREME 160R PROGRAMMED FI - LEFT SIDE VIEW; Left Side View Components

5
*Accessories and features shown may not be part of standard fitment.
(1) Side reflex reflector
(2) Throttle body/ECU
(inside)
(3) Starter motor
(4) Gear shift pedal
(7) Rider foot rest
(6) Side stand
(9) Saree guard
(5) Main stand
(8) Pillion foot rest (13) Side stand switch
(10) Rear grip
(11) Seat lock
(12) Battery compartment (inside)
LEFT SIDE VIEW
