5.3.1 Operating auxiliary rear/brake lights
Depending on configuration, an auxiliary rear/brake light will be active
as a rear running light whenever the ignition switch is ON, and be active
as a brake light whenever the brakes are used. To use this feature, set
one or more power circuits to power auxiliary rear/brake lights. The
Auxiliary Brake Light section of the ezCAN configuration software
(below) will be shown.
5.3.2 Operating run/brake/turn lights
Depending on configuration, a run/brake/turn light will be active as a
running light (in other words, at a lower brightness than brake light
brightness) whenever the ignition switch is ON, active as a brake light
whenever the brakes are used, and be active as a turn signal whenever
the turn signal for the relevant side is switched on. To use this feature, set
one or more power circuits to power left or right run/brake/turn lights. The
Run/Brake/Turn Light section of the ezCAN configuration software will
be shown (below, left). This section of the software is associated with the
Brake Left and Brake Right circuit configuration options (below, right).
5.3.3 Operating 12-volt accessory power sockets
If a power circuit is set as a 12-volt accessory circuit, it will supply full
battery voltage whenever the ignition switch is ON. To use this feature, set
one or more power circuits to power an accessory circuit. The Accessory
/ Ignition Supply section of the ezCAN configuration software (below) will
be shown.
This function has a configurable delay time-out (to a maximum of 60
seconds) that will keep the output ON for the configured time after the
motorcycle’s ignition has been switched OFF.
