Hex ezCAN for CAN-bus-equipped Motorcycles
_________________________________________________________________________________________________
_________________________________________________________________________________________________
© Hex Innovate (UK) Ltd. Page 22 of 60 ezCAN 2408.x
5 HOW TO CONTROL YOUR EZCAN
Some aspects of ezCAN operation differ depending on motorcycle make
and model. This section contains all rider actions needed to switch on,
adjust, and switch off all functions on all compatible motorcycles.
Some rider actions may give different results, depending on how the
ezCAN is configured. To learn how to configure your ezCAN using the
configuration software, click here.
In all cases, the motorcycle’s ignition switch must be ON.
5.1 Operating auxiliary front lights
5.1.1 BMW
5.1.1.1 All Motorcycles with Multi-Controller
If an ezCAN is installed on any compatible BMW model with a rotary Multi-
Controller on the left-side handlebar controls, the ezCAN is controlled
using the Multi-Controller.
Adjusting Aux 1 lights
only
1. Hold the Multi-Controller LEFT until the Aux 1 lights flash
twice.
The Aux 1 lights are now in brightness-adjustment
mode.
2. Rotate the Multi-Controller UP to increase light
brightness by 10% per click (to a maximum of 100%), or
DOWN to decrease brightness by 10% per click (to a
minimum of 0%).
3. Exit brightness-adjustment mode by not operating the
Multi-Controller for more than 5 seconds.
IMPORTANT
The ezCAN will need to be configured before it works in
exactly the way you want it to.
For detailed instructions on how to configure the ezCAN
using the ezCAN configuration software, click here.
WARNING
For safety reasons, it is strongly recommended that you
stop the motorcycle and select Neutral gear before
switching on, adjusting or switching off auxiliary front lights.
If your KTM does not have an optional Hex light switch
installed, it is not possible to adjust auxiliary front lights, or
switch them ON or OFF, while the motorcycle is moving.
