Adjusting Aux 2 lights
only
1. Press and hold the left switchgear INFO button until all
auxiliary front lights flash twice.
 The auxiliary front lights are now in brightness-
adjustment mode.
2. Release the INFO button.
3. Pull in and hold the clutch lever.
4. Briefly press and release the INFO button to adjust light
brightness.
 Each press will brighten the Aux 2 lights by 10%
to a maximum of 100%, then roll brightness
through to 0% (OFF).
 You can repeat this cycle as many times as you
need.
5. Release the clutch lever.
6. Exit brightness-adjustment mode by not operating the
INFO button for more than 5 seconds.
Toggling Aux 1 lights
On and Off
Press and hold the left switchgear INFO button for more than
7 seconds. The state of the lights persists even if the ignition
is cycled.
Toggling Aux 2 lights
On and Off
1. Pull in and hold the clutch lever.
2. Press and hold the left switchgear INFO button for more
than 7 seconds. The state of the lights persists even if
the ignition is cycled.
Temporarily switching
off all front and rear
auxiliary lights
Press and hold the left switchgear INFO button for more than
10 seconds.
If all front and rear auxiliary lights are temporarily switched
off, the ezCAN will turn the rear auxiliary lights back on:
 Whenever Aux 1 or Aux 2 lights are turned back on.
 After the ignition switch is cycled.
Strobing Aux lights on
‘Flash-to-pass’
Click the motorcycle’s ‘Flash-to-pass’ button three times.
Note that to be active, this function must be enabled using
the ezCAN configuration interface.
5.1.2 Harley-Davidson
5.1.2.1 ezCAN Laconia
Applicable models:
 Pan America 1250
NOTES
If all front and rear auxiliary lights are temporarily switched
off (see table above), these lights will be switched back on
when the ignition is cycled.
Alternatively, Aux1 and/or Aux 2 lights can be switched
back on using the Toggling Aux 1/2 lights On and Off
functions (see table above).
When using the Toggling Aux 1/2 lights On and Off
functions, note that any rear auxiliary (Run/Brake) lights will
be switched back on whenever Aux 1 and/or Aux 2 lights
are switched back on.
