5.1.8 Yamaha
5.1.8.1 ezCAN II Yari
Applicable models:
 Ténéré 700 (2019+)
If an ezCAN II Yari is installed on a Ténéré 700 manufactured between
2019 and 2022, the ezCAN can be controlled using the Bottom set button
on the motorcycle’s instrument cluster (red arrow, below left), and the
SELECT switch on the right-side handlebar controls (red arrow, below
right).
Adjusting Aux 1 lights
only
1. Press and hold the Bottom set button / SELECT switch
until the Aux 1 lights flash twice.
 The Aux 1 lights are now in brightness-adjustment
mode.
2. Briefly press and release the Bottom set button /
SELECT switch to adjust light brightness.
 Each press will brighten the Aux 1 lights by 10%
to a maximum of 100%, then roll brightness
through to 0% (OFF).
 You can repeat this cycle as many times as you
need.
3. Exit brightness-adjustment mode by not operating the
Bottom set button / SELECT switch for more than 5
seconds.
Adjusting Aux 2 lights
only
The brightness of Aux 2 lights cannot be adjusted using the
motorcycle’s controls.
If needed, adjust the brightness of Aux 2 lights using the
Auxiliary Lights Two section of the ezCAN user interface.
Toggling Aux 1 lights
On and Off
Press and hold the Bottom set button / SELECT switch until
the Aux 1 lights fade off, or fade on (depending on whether
the lights were on or off.)
 If the Aux 1 lights were on, it is normal for them to
flash twice before they fade off.
 The state of the lights persists even if the ignition is
cycled.
