4 EZCAN INSTALLATION TUTORIALS
A number of video tutorials are available for every ezCAN-related topic.
To see relevant video tutorials, click the links below.
Videos are added on a regular basis. Please visit www.hexezcan.com to
see the latest additions.
4.1 ezCAN installation instructions
The ezCAN installation video tutorials give specific, easy-to-follow
instructions. For instructions on how to install an ezCAN on any
compatible motorcycle, click here.
4.2 ezCAN configuration instructions
You will see the view below when you click the configuration icon for any
output circuit.
You can assign any of the configuration options you see in the white
portion above to each of the four power output circuits.
NOTES
The Red Circuit, Blue Circuit, Yellow Circuit and White
Circuit correspond to the actual wire colours on the relevant
ezCAN output circuits.
