Hexagon m&h 40.02-IRP User Manual

IRP40.02 Description
37
Shanks THERMO-LOCK
®
(patented)
INFORMATION
Patented THERMO-LOCK
®
Technology prevents thermal expansion of the HSK and heat transfer from the
spindle to the probe. This ensures that the probe delivers stable, precise results even for large temperature
differences between the spindle and the HSK.
Available shanks
Length "L" (refer to Fig. 5)
Order Number
DIN69893 HSK-E32
86 mm (3.39”)
40.02-HSK32E-TI
DIN69893 HSK-40
86 mm (3.39”)
40.02-HSK40-TI
DIN69893 HSK-E40
86 mm (3.39”)
40.02-HSK40E-TI
DIN69893-HSK-A50
92 mm (3.62”)
40.02-HSK50A-Tl
DIN69893 HSK-E50
92 mm (3.62”)
40.02-HSK50E-TI
DIN69893 HSK-A63
92 mm (3.62”)
40.02-HSK63A-TI
Other Shanks
Upon request
Shanks Coromant Capto
Available shanks
Length "L" (refer to Fig. 5)
Order Number
Coromant Capto C4
86 mm (3.39”)
40.02-C4
Coromant Capto C5
86 mm (3.39”)
40.02-C5
Coromant Capto C5
121.5 mm (4.78”)
40.02-C5-121,5
Coromant Capto C5-90°
102.5 mm (4”)
40.02-C5-90
Coromant Capto C6
92 mm (3.62”)
40.02-C6
Coromant Capto C6
121.5 mm (4.78”)
40.02-C6-121,5
Coromant Capto C6-90°
102.5 mm (4”)
40.02-C6-90
Coromant Capto C8
92 mm (3.62”)
40.02-C8
Coromant Capto C8
121.5 mm (4.78”)
40.02-C8-121,5
Coromant Capto C8-90°
102.5 mm (4”)
40.02-C8-90
Other Shanks
Upon request
Shanks VDI
Available shanks
Length "L" (refer to Fig. 5)
Order Number
VDI 16
75 mm (2.95”)
40.02-VDI16
VDI 16-90°
56 mm (2.2”)
40.02-VDI16-90
VDI 20
75 mm (2.95”)
40.02-VDI20
VDI 20-90°
56 mm (2.2”)
40.02-VDI20-90
VDI 25
75 mm (2.95”)
40.02-VDI25
VDI 25-90°
56 mm (2.2”)
40.02-VDI25-90
VDI 30
79 mm (3.11”)
40.02-VDI30
VDI 30-90°
60 mm (2.36”)
40.02-VDI30-90
VDI 40
98.5 mm (3.38”)
40.02-VDI40
VDI 40-90°
79.5 mm (3.13”)
40.02-VDI40-90
VDI 50
98.5 mm (3.38”)
40.02-VDI50
VDI 50-90°
79.5 mm (3.13”)
40.02-VDI50-90
VDI 60
98.5 mm (3.38”)
40.02-VDI60
VDI 60-90°
79.5 mm (3.13”)
40.02-VDI60-90
VDI 80
98.5 mm (3.38”)
40.02-VDI80
VDI 80-90°
79.5 mm (3.13”)
40.02-VDI80-90
Other Shanks
Upon request
