Hexagon m&h 40.02-IRP User Manual

Description IRP40.02
38
Other Shanks
Available shanks
Length "L" (refer to Fig. 5)
Order Number
D20-D8-L25-B
65 mm (2.56”)
40.02-D8-L25
D20-D32-L100-B
62 mm (2.44”)
40.02-D32-L100
NIKKEN-NC5-46
115.5 mm (4.55”)
40.02-NC5-46
NIKKEN-NC5-63
115.5 mm (4.55”)
40.02-NC5-63
D20-Erowa-ITS
91 mm (3.58”)
40.02-ITS
1.7.4 Accessories, general
Order No.
Description
Illustration
91.00-SWV-XX
(upon request)
Air jet with rotary joint for VDI shanks
D20-VDI-90 90°Adapter for shank VDI
D20-MO-B Modular adapter D20/D28 (Ø20/Ø28)
1.7.5 Spare Parts
Order No.
Description
Illustration
4316 Battery (3,6 V / ½ AA)
40.02-
BATTERIE-
DECKEL
Battery cover
5764 Battery cover lock
5186 O-Ring 20x1 Viton for battery cover
1351 Clamping screw AF2,5 mm
1352 Adjustment screw DIN913 M4x8 (AF2 mm)
5773 Service cover
6161 O-Ring 23x1 Viton for service cover
