x.Spot ™User Manual General Maintenance 6-9
6
Wire Harness Connections
LITETOUT LAMP TOUT Throughout fixture
Lamp is off:
1. Lamp may by too hot to strike. Wait several minutes for lamp to cool,
try striking lamp, see“Lamp State” on page 3-23.
2. Verify Pan board with another 3-phase board from fixture,
see“Replacing a Driver Board” on page 5-6.
3. Check that wire harness is connected and undamaged.
4. Check for damage to lamp or interlock switch. To replace lamp, see
“Replacing the Lamp” on page 5-4.
5. Relay, Lamp power supply, or ignitor needs to be replaced.
Display Error Messages
8 Character
Error Message
16 Character Error
Message
Location
Problem/Procedure
For replacement parts, see “Contacting High End Systems®” on page ii
lamp power supply pan board
lamp power supply ignitor
lamp power supply relay
ignitor harness ignitor board
ignitor board relay ignitor
harness lamp socket
top box harness relay
top box harness pan board
main head harness interlock switch
tilt harness pan harness
pan harness top box harness
tilt harness main head harness
