6-8 General Maintenance x.Spot ™User Manual
EDGEFRST
FROST HOMING
EDGE NOT FOUND
Focus/Frost/Zoom module 2
phase board, motor M1, sensor
S3
Frost not homing correctly:
1. Check Frost sensor connection at sensor and board.
2. Check Frost motor wire connection at motor and board.
3. Check for wire damage.
4. Verify board functioning by substituting with another 2-phase board
from the fixture, see “Replacing a Driver Board” on page 5-6.
5. Check that Frost sensor tab is installed and operating.
6. Check that Frost gear set screw is tight.
7. Check that Frost gear is aligned with frost flag teeth.
8. Replace motor.
SLOT 1 ID
MODULE SLOT 1
CONFIG CHANGE
Module in Slot 1
CPU did not find module:
1. Check that module is assigned to slot ID, see “Module Configuration
Menu” on page 3-20.
2. Check that module is plugged into head harness.
3. Check head harness, tilt harness, pan harness, top box harness for
connection and damage, see “Wire Harness Connections” on page
6-9.
4. Check if motor power supply output fuse is blown, see “Replacing
Fuses” on page 5-2.
SLOT 2 ID
MODULE SLOT 2
CONFIG CHANGE
Module in Slot 2
SLOT 3 ID
MODULE SLOT 3
CONFIG CHANGE
Module in Slot 3
Display Error Messages
8 Character
Error Message
16 Character Error
Message
Location
Problem/Procedure
For replacement parts, see “Contacting High End Systems®” on page ii
