x.Spot ™User Manual General Maintenance 6-7
6
EDGEFCS1
FOCUS 1 HOMING
EDGE NOT FOUND
Focus/Frost/Zoom module 2
phase board, motor M3
Focus not homing correctly:
1. Focus homing tab not installed.
2. Check focus wire connection at motor and board.
3. Verify board functioning by substituting with another 2-phase board
from the fixture, see “Replacing a Driver Board” on page 5-6.
4. Check that focus sensor is installed and functioning.
5. Check focus sensors S1 & S4 connection at sensor and board.
6. Check for focus wire harness damaged.
7. Replace motor.
EDGEFCS2
FOCUS 2
HOMING EDGE
NOT FOUND
Focus/Frost/Zoom module 2
phase board, motor M4
OPENZOOM
ZOOM HOMING
OPEN NOT FOUND
Focus/Frost/Zoom module 2
phase board, sensor S2 and M2
Zoom not homing correctly:
1. Check Zoom sensor connections at sensor and board.
2. Check Zoom motor wire connections at motor and board.
3. Check for wire damage.
4. Verify board functioning by substituting with another 2-phase board
from the fixture, see “Replacing a Driver Board” on page 5-6.
5. Check that Zoom sensor is installed and operating.
6. Check that sensor wheel is installed.
7. Check that pinion gear set screw is tight.
8. Check that Zoom belt is installed and undamaged.
9. Check for Zoom lens damage.
10.Replace motor.
CLOSZOOM
ZOOM HOMING
CLOSING NOT
FOUND
Focus/Frost/Zoom module 2
phase board, motor M2
Display Error Messages
8 Character
Error Message
16 Character Error
Message
Location
Problem/Procedure
For replacement parts, see “Contacting High End Systems®” on page ii
