6-6 General Maintenance x.Spot ™User Manual
GOBO1TAB
GOBO 1 HOMING
TAB NOT FOUND
Dual litho module M2
Gobo wheel is not homing correctly:
1. Check and clear any wheel obstructions.
2. Check wheel wire connection at motor and board.
3. Verify board functioning by substituting with another 2-phase board
from the fixture, see “Replacing a Driver Board” on page 5-6.
4. Check that set screws on wheel hub and drive gear hub are tight.
5. Check that wheel sensor S1 is installed and connected at sensor and
board and is operating.
6. Check for wheel wire harness damaged, see “Wire Harness
Connections” on page 6-9.
7. Check that Drive gear is aligned with wheel gear.
8. Check if missing thrust washer is causing two wheels to move
simultaneously.
9. Check for wheel damage
10.Replace wheel motor.
EFFECT
EFFECT HOMING
TAB NOT FOUND
Dual litho module M3
GOBO2TAB
GOBO 2 HOMING
TAB NOT FOUND
Litho/Iris module M2
GOBO1TAB
GOBO 1 ROTATE
TAB NOT FOUND
Dual litho module M4
Litho rotate not homing correctly:
1. Check for rotate sensor tab obstructions.
2. Check rotate wire connection at motor and board.
3. Check rotate sensor connection at sensor and board.
4. Verify board functioning by substituting with another 2-phase board
from the fixture, see “Replacing a Driver Board” on page 5-6.
5. Check that rotate sensor is installed and undamaged.
6. Check that set screws on drive gear hub and rotate gear hub are
tight.
7. Check that drive gear is aligned with rotate gear.
8. Check for rotate or sensor wire damage.
9. Replace motor.
EFFECT
EFFECT ROTATE
TAB NOT FOUND
Dual litho module M1
GOBO2TAB
GOBO 2 ROTATE
TAB NOT FOUND
Litho/Iris module M1
Display Error Messages
8 Character
Error Message
16 Character Error
Message
Location
Problem/Procedure
For replacement parts, see “Contacting High End Systems®” on page ii
