Network Video Recorder User Manual
128
Step 1 Go to the Linkage Action interface of the alarm input or event detection (e.g., motion detection,
facial detection, line crossing detection, intrusion detection, etc.).
Step 2 Click the Trigger Alarm Output tab.
Step 3 Select the alarm output (s) to trigger.
Step 4 Go to System > Event > Normal Event > Alarm Output.
Step 5 Select an alarm output item from the list.
Refer to Chapter 11.6.3 Configure Alarm Output for the alarm output settings.
11.2.6 Configure PTZ Linkage
The system can trigger the PTZ actions (e.g., call preset/patrol/pattern) when the alarm event, or
VCA detection events occur.
Make sure the PTZ or speed dome connected supports PTZ linkage.
Step 1 Go to the Linkage Action interface of the alarm input or VCA detection (e.g., facial detection,
line crossing detection, intrusion detection, etc.).
Step 2 Select the PTZ Linkage.
Step 3 Select the camera to perform the PTZ actions.
Step 4 Select the preset/patrol/pattern No. to call when the alarm events occur.
Figure 11-3 PTZ Linkage
You can set one PTZ type only for the linkage action each time.
