Network Video Recorder User Manual
23
Table 1-5 Panel Description
Locks or unlocks the panel by the key.
Turn on/off device.
Solid blue: Device is on.
Solid red: Device is off.
Turn on/off alarm beep.
Solid blue: Alarm sound is off.
Unlit: Alarm sound is on.
Solid red: At least one HDD is installed.
Unlit: No HDD is detected.
Flashing red: HDD is reading/writing.
Flashing blue: Network transmission is normal.
USB 2.0 interface for additional devices such as USB mouse
and USB Hard Disk Drive (HDD).
7-inch LCD for live-view image and menu operation.
