35
7
VGA
DB9 connector for VGA output. Display local
video output and menu.
8
RS-485 Interface
Half-duplex connector for RS-485 devices.
9
ALARM IN
Connector for alarm input.
ALARM OUT
Connector for alarm output.
10
GROUND
Ground (needs to be connected when NVR
starts up).
11
Power Supply
100 to 240 VAC power supply.
12
Power Switch
Switch for turning on/off the device.
13
Network Interfaces with PoE
Function
Network interfaces for the cameras and to
provide power over Ethernet.
14
eSATA Interface
Connects external SATA HDD, CD/DVD-RM.
15
VIDEO OUT
BNC connector for video output.
