HIKVISION DS-19S08N-04F/K Series User Manual

Video Security Control Panel User Manual
--137-
-
Working Status
Indicator Status
Working Status
Indicator Status
Project
Red, Normally On
Change Password
Green. Blink
LED alarm keypad Channel indicator:
Working Status
Indicator Status
Working Status
Indicator Status
Sensor Normal
Off
Sensor Error
Red, Normally On
Sensor Alarm
Red, Blink
Sensor Bypass
Green, Normally On
LED keypad Channel indicator under Project Mode:
No.
Description
No.
Description
1
Off-hook
5
Send CID Report
2
Dial
6
Receive Alert Sound
3
Alarm Connecter Disconnection
7
control panel Off-hook
4
Receive the Hand-shack Sound
8
Alarm Connector On-hook
LED keypad Channel indicator under Status Mode:
No.
Description
No.
Description
1
AC Power off
5
Keypad Off-line
2
Battery Low Voltage
6
Network Cable Off-line
3
control panel Tamper-proof On
7
No SIM Card
4
ADSL Cable Off-line
8
Reserved
Q: What is the meaning of LED keypad alert sound?
A: The meanings of LED keypad alert sound are as follow:
No.
Keypad Alert Sound
Description
1
1 Sound
Keypad Prompt, Error Operating Prompt
2
2 Sound
Correctly answered, report uploading succeeded
3
5 Sound
Incorrectly answered, report uploading failed in 60s
4
Last for 2s
Error Prompt
5
Intermittent Slow Sound, Continuously
Enter/Exit Delay
6
Intermittent Rapid Sound, Continuously
Enter/Exit Delay, 10s Left
