Video Security Control Panel User Manual
{3} Trigger No.: Hundreds’ Digit
{4} Trigger No.: Tens’ Digit
{5} Trigger No.: Digit
{6} End the command.
Trigger Schedule Time Parameter Settings
To configure the time parameters of the trigger schedule, please refer to the command below.
699 0 0 0 0 0 0 0 0 0 E #
1
2 4 63 5
87
9
10
11 12
{1} Trigger Schedule Time Parameter Settings Command Address: 699.
{2} It presents the time bucket composed by {3} ~ {10}. The value range is 1~8.
{3}~{10} It indicates the start time and end time during the time bucket of {2}.
Start Time: {3}{4}:{5}{6}
End Time: {7}{8}:{9}{10}
When you set the start and end time as 00:00 and 00:00, all the settings from the present time bucket
to the maximum time bucket will be cleared.
When you set the start and end time as non-zero, the previous time bucket must be non-zero.
When you set the start and end time as non-zero, only Enable in {11} can be set.
When you set the start and end time as non-zero, end time must be greater than start time in every
time bucket.
When you set the start and end time as non-zero, the start time must be 5min greater than the end
time of the previous time bucket.
When you set the start and end time as non-zero, if the time bucket is overlapped with the latter ones,
or the difference between them is less than 5min, all the settings of the latter ones will be cleared.
{11} Enable/disable the trigger schedule.
