User Manual of WIFI Network Video Recorder
150
12.1 Initializing HDD
Purpose:
The hard disk drive (HDD) must be initialized before using it.
A message box pops up when the NVR starts up if there exits any uninitialized HDD.
Figure 12. 1 Message Box of Uninitialized HDD
Click Yes to initialize it immediately or you can perform the following steps to initialize the HDD.
Steps:
1. Enter the HDD Information interface.
Menu > HDD > General
Figure 12. 2 HDD Information Interface
2. Select HDD to be initialized.
3. Click the Init button.
Figure 12. 3 Confirm Initialization
4. Select the OK button to start initialization.
Figure 12. 4 Status changes to Initializing
5. After the HDD has been initialized, the status of the HDD will switch from Uninitialized to Normal.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-7108NI and is the answer not in the manual?

HIKVISION DS-7108NI Specifications

General IconGeneral
ModelDS-7108NI
Channels8
HDD Bays1
Recording Resolution8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
SATA1 SATA interface
Operating Humidity10% to 90%
TypeNetwork Video Recorder
Max HDD Capacity6TB
Video Output1 × VGA, 1 × HDMI
HDMI Output Resolution1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output Resolution1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio Input1-channel RCA
Audio Output1-channel RCA
Decoding FormatH.264
Resolution8MP
Capability8-ch @1080p
Network Interface1 RJ45 10M/100M self-adaptive Ethernet interface
USB Interface2 USB 2.0
Operating Temperature-10 °C to +55 °C (+14 °F to +131 °F)
