HIKVISION DS-7108NI User Manual

User Manual of WIFI Network Video Recorder
89
7.2 Managing Backup Devices
Management of USB flash drives and USB HDDs
Steps:
1. Enter Search Result interface of record files.
Menu > Export > Normal
2. Set search conditions, including IP Camera, Record Type, File Type, Start Time and End Time.
3. Click Search button to enter Search Result interface.
Figure 7. 17 Normal Video Search for Backup
4. Click to select the List tab.
5. Click Export All button to export all the record files.
Or you can select record files to back up, and click Export button to enter Export interface.
Figure 7. 18 Result of Normal Video Search for Backup
6. Backup device management.
 Select external device and file type in respective dropdown lists.
 Click New Folder button if you want to create a new folder in the backup device.
 Select a record file or folder in the backup device and click button if you want to delete it.
 Click Format button to format the backup device.

HIKVISION DS-7108NI Specifications

General

Model	DS-7108NI
Channels	8
HDD Bays	1
Recording Resolution	8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
SATA	1 SATA interface
Operating Humidity	10% to 90%
Type	Network Video Recorder
Max HDD Capacity	6TB
Video Output	1 × VGA, 1 × HDMI
HDMI Output Resolution	1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output Resolution	1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio Input	1-channel RCA
Audio Output	1-channel RCA
Decoding Format	H.264
Resolution	8MP
Capability	8-ch @1080p
Network Interface	1 RJ45 10M/100M self-adaptive Ethernet interface
USB Interface	2 USB 2.0
Operating Temperature	-10 °C to +55 °C (+14 °F to +131 °F)
