HIKVISION DS-7108NI User Manual

User Manual of WIFI Network Video Recorder
168
14.5 Upgrading System
Purpose:
The firmware on your NVR can be upgraded by local backup device or remote FTP server.
14.5.1 Upgrading by Local Backup Device
Before you start:
Connect your NVR with a local backup device where the update firmware file is located.
Steps:
1. Enter the Upgrade interface.
Menu > Maintenance > Upgrade
2. Click the Local Upgrade tab to enter the local upgrade menu, as shown in Figure 14. 8.
Figure 14. 8 Local Upgrade Interface
3. Select Device Name and File Type you want to show in respective dropdown lists.
The default File Type is *.dav and *.mav.
4. Click to select the update file in the backup device.
5. Click Upgrade to start upgrading.
6. After the upgrading is complete, reboot the NVR to activate the new firmware.
14.5.2 Upgrading by FTP
Purpose:
Ensure the network connection of the PC (running FTP server) and the device is valid and correct. Run the FTP
server on the PC and copy the firmware into the corresponding directory of your PC.

HIKVISION DS-7108NI Specifications

General

Model	DS-7108NI
Channels	8
HDD Bays	1
Recording Resolution	8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
SATA	1 SATA interface
Operating Humidity	10% to 90%
Type	Network Video Recorder
Max HDD Capacity	6TB
Video Output	1 × VGA, 1 × HDMI
HDMI Output Resolution	1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output Resolution	1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Audio Input	1-channel RCA
Audio Output	1-channel RCA
Decoding Format	H.264
Resolution	8MP
Capability	8-ch @1080p
Network Interface	1 RJ45 10M/100M self-adaptive Ethernet interface
USB Interface	2 USB 2.0
Operating Temperature	-10 °C to +55 °C (+14 °F to +131 °F)
