23
Live Preview On-screen Display
The Live Preview mode is automatically started after the DVR boots up. It is also at the very top of the menu hierarchy,
thus hitting the ESC multiple times (depending on which menu you’re on) will bring you to the Live Preview mode.
Live Preview Icons
Some icons are provided on screen in Live Preview mode to indicate different camera status. These icons include:
Event Alarm: Indicates video loss, video tampering, motion detection or relay alarm.
Record: Indicates the current channel is recording. The recording may have been started manually, from
a schedule, and/or triggered from motion or alarm.
Event Alarm & Record
Figure 1. Live Preview Icons
Note:
Status for video loss alarm is only valid with analog cameras.
Live Preview Operation
In Live View mode, you can operate the following functions:
1. Display Single Camera:
• By Front Panel/Remote: Use Alphanumeric buttons.
• By Mouse: Select Single Camera in right-click menu.
2. Multi-camera Preview:
• By Front Panel/Remote: Press PREV button.
• By Mouse: Select Multi Camera in right-click menu.
3. Manual Switch:
• By Front Panel/ Remote: Press the Left arrow button to access the previous screen; press the Right
arrow button to access next screen.
• By Mouse: Select Next Screen in right-click menu.
4. Auto Sequence:
• By Front Panel/Remote: Press Enter button.
• By Mouse: Select Start Auto-switch in right-click menu.
5. Digital Zoom:
• By Mouse: Select Digital Zoom in right-click menu.
Mouse Operation in Live Preview
Some functions of the Live Preview can be quickly accessed by clicking the right-button of the mouse (shown in Figure
2). These functions include:
To Next Page
