87
2. Configure RS-232 Settings.
3. The RS-232 port can be used in two ways:
• Parameter Control: Connect a PC to the DVR using the PC serial port. Device parameters can then
be set using software such as HyperTerminal. The serial port parameters must be the same as the
DVR’s when connecting with the PC serial port.
• Transparent Channel: Connect a serial device directly to the DVR. The serial device will be
controlled remotely by the PC through the network and the protocol of the serial device.
Note:
DS-7604 Series DVR provides no RS232 port, thus it is unallowable to set parameters control or create
transparent channel.
Managing User Accounts
By default settings, your DVR is configured with the user name of admin and the password of 12345. The
Administrator has the authority to add, delete or configure the user parameters.
Add a New User
To add a new user:
Click Menu > Setting > User to enter the User Settings menu, shown in Figure 4.
Figure 4. User Settings Menu
1.
Select the Add button to enter the Add User menu, shown in Figure 5.
Note:
Up to 31 users can be added.
