HIKVISION DS-81 Series User Manual

Storage System User Manual
32
Figure 4. 11 Storage Pool
Table 4. 5 Interface Description
Area
Name
Description
1
Information Area
Lists the storage pool total size, free size, LUN size, snapshot size,
HYBRID SAN size, iSCSI size, and FC size.
2
Configuration Area
You can add, delete, and positioning created physical volume here.
4.3.1 Adding Storage Pool
Purpose:
You need to create physical volumes to build storage pool.
Before you start:
Ensure available array or HDD exists in the storage system.
Steps:
1. Click Add.
Figure 4. 12 Add Storage Pool
2. Select at least one array or HDD as storage pool.
Or select the combination of array or HDD.
3. Input PV Name in text field.
