6.1 One-Key Configuration
Purpose:
Quick-setting creating helps you to create HYBRID SAN quickly.
Before you start:
Ensure there is neither storage pool nor array in the storage system.
Steps:
1. Click the One-Key Configuration button in upper right corner to start quick settings.
2. Click OK to confirm. Quick-setting takes 3 to 15 minutes. During the quick-settings, following operations are
performed automatically.
1) Add HDDs to storage pool. Or create RAIDs and add them to storage pool.
The whole HDDs are added to storage pool with no more free capacity. You can view the storage pool
usage in Storage › Storage Pool.
2) Create private volume, reserved volume, and record volume. If more than 3 LUNs are created, one
archive volume is created.
Figure 6. 3 HYBRID SAN Settings Interface
 Bad HDD, risky HDD, and warning HDD would not be added to storage pool.
 Non-enterprise HDD is added to storage pool by single-HDD mode.
 Quick-setting takes longer if any undetected HDD exists.
 If HDDs in the storage system are less than 6, they are added to storage pool by single-HDD mode.
 If HDDs in the storage system are not less than 6 and HDDs in storage enclosure is less than 6, the
storage system HDDs are added by array mode and the storage enclosure HDDs won’t be added.
 If HDDs in the storage system and HDDs in storage enclosure are both not less than 6, they are both
added to storage pool by array mode.
 If only one HDD exists, no reserved volume is created. In single-HDD mode, no reserved volume is
created in the last HDD of the storage system. In array mode, two reserved volumes are created in each
RAID.
 By default, a 50 GB size private volume and a 50 GB size reserved volume should be created.
6.2 HYBRID SAN Configuration
Purpose:
